iTECH Universal Vacuum Table Kit for CNC Router - Tool Free Clamping !

iTECH Universal Vacuum Table Kit for CNC Router - Tool Free Clamping !

Regular price £1,100.00 GBP
Regular price Sale price £1,100.00 GBP
Sale Sold out
Shipping calculated at checkout.
A compact vacuum table designed for use on our desktop range of CNC machines but which also has a wider use in clamping and holding of boards for edgebanding and other operations where it is important to hold the board secure whilst machining.
Ideal for nesting work (cutting multiple parts from a sheet) it is nessary to place a sacrificial mdf board on top of the bed. if you are simply engraving or not cutting through then you can work directly on the surface of the table. The table is supplied with plugs to block off unwanted vacuum zones of the table. It is also supplied with T slots for mechanical clamping should the workpiece be too small or narrow for an effective vacuum hold down. Installation:
exhaust from the vacuum table is on the underside to keep the work area completely clear - Thus you will have to cut a hole in the bed of the machine to install the vacuum bed and a hole in te frame end of the machine for the tube to exit. the table can simply then be screwed to the existing bed

Technical Specification:
table size 635 x 935mm
table thickness 40mm
material heavy duty PVC
groove size 10mm
mechanical clamp strips 4
vac cord 10-12mm
vacuum pump 2.2Kw
voltage 240V 1 phase
sound level 72 db

Shipping & Delivery

Price includes shipping on flat vehicle to UK mainland address. Crane vehicles can be booked at extra cost
